PA101, Ion exchange resin, strong base anion — Type I, gel

Type I anion · Cl⁻ form

PA101

Ion exchange resin, strong base anion — Type I, gel

Manufacturer: Pure Resin

Pure PA101 is a Type I gel strong base anion exchange resin that combines high operating capacity with low residual silica. It is supplied as spherical beads in the chloride form and is also available in the OH⁻ form. It is meant for regeneration-efficient demineralisation including silica removal, for all types of deionisation systems and chemical processing. It is especially suited to mixed bed and layered bed demineralisers.

Request a quote0886 834 717

Price and delivery time on request. Working hours: Mon–Fri, 8:30–17:00

Features

What PA101 offers

  • High operating capacity
  • Low residual silica
  • Efficient regeneration with NaOH
  • Available in Cl⁻ or OH⁻ form
  • For mixed and layered beds
  • Gel polystyrene matrix with DVB

Applications

Where it is used

  • Demineralisation
  • Silica removal
  • Deionisation systems
  • Mixed and layered beds
  • Chemical processing
Supply, installation and serviceService and maintenance

Technical data

PA101 specifications

Typical physical and chemical characteristics

Polymer matrix
Polystyrene crosslinked with DVB
Functional group
R–N(CH₃)₃⁺
Ionic form, as shipped
Chloride (Cl⁻)
Physical form and appearance
Clear spherical beads
Sphericity
95% min.
Screen size range (U.S. Standard Screen)
16–50 mesh (wet)
Particle size range
+1.2 mm < 5%, −0.3 mm < 1%
Uniformity coefficient
1.6 max.
Water retention, Cl⁻ form
48–58%
Swelling Cl⁻ → OH⁻
20–30%
Shipping weight, Cl⁻ form
660–710 g/l (≈ 43 lbs/cu.ft)
Total exchange capacity, Cl⁻ form
1.3 eq/l min.
pH range
0–14

Suggested operating conditions

Max. temperature, Cl⁻ form
100 °C (212 °F)
Max. temperature, OH⁻ form
60 °C (140 °F)
Min. bed depth
0.6 m (24 in)
Backwash
50–75% bed expansion
Regenerant
NaOH 2–6%
Regenerant flow rate
2–8 BV/h (0.25–1.00 gpm/cu.ft)
Regenerant contact time
60 minutes min.
Displacement rinse rate
same as the regenerant flow rate
Displacement rinse volume
10–15 gal/cu.ft (≈ 1.3–2 BV)
Fast rinse rate
same as the service flow rate
Fast rinse volume
35–60 gal/cu.ft (≈ 4.7–8 BV)
Working flow rate
16–32 BV/h (2.0–4.0 gpm/cu.ft)

Hydraulic properties

Pressure drop
Pressure dropExpected pressure loss per foot of bed depth as a function of flow rate, at various temperatures.
Backwash
BackwashAfter each cycle the bed is backwashed at a rate that expands it by 50 to 75%. This removes foreign matter and reclassifies the bed. The graph shows the bed expansion in % for PA101 in the Cl⁻ form.
  • The graphs use the manufacturer's units: 1 gpm/sq.ft ≈ 2.44 m/h, 1 psi/ft ≈ 0.23 bar/m, 40 °F ≈ 4 °C, 60 °F ≈ 16 °C, 80 °F ≈ 27 °C, 90 °F ≈ 32 °C, 100 °F ≈ 38 °C.
